Fly Screen Systems


Every Opening Has a Screen Built For It
A wide sliding balcony, a floor-to-ceiling window, a narrow door frame — each opens differently, so each needs a different mechanism. King Space builds three: Zipline for wide spans that lock flat against wind, Motorized for hands-free daily use, and Pleated for tight frames that can't spare the depth.

Made to Order:
Every unit is measured to your opening and built in-house — sample production in 2–3 days, mass production in 7–10, and 100% QC inspection before it ships. OEM/ODM work is available on request.

CHOOSING BETWEEN THE THREE
Widest openings and heaviest wind exposure call for Zipline. Daily-use doors and pergolas that you'd rather not lift by hand call for Motorized. Narrow frames with only 22mm of depth to spare call for Pleated. Not sure which fits? Send us the opening size and we'll tell you.

Get a Quote
Fly Screen Systems
Our Systems

Three mechanisms, one purpose

Sys.01 — Manual

Zipline

Locked flat under heavy wind

Max width12m
Max height4.5m
Warranty5 years
View specifications →
Sys.02 — Automated

Motorized

Somfy-driven, remote or smart-home

Max width10m
Max height5m
Motor warranty10 years
View specifications →
Sys.03 — Retractable

Pleated

22mm frame depth, slim stack

Max width9m
Max height3.3m
Warranty3 years
View specifications →
System 01 — Manual Zip Series

Strength meets serenity

A double suspended track keeps the screen locked flat under heavy wind, sliding open across spans up to 12m wide and 4.5m high. One fabric, several jobs: privacy, sun control, dust and insect protection.

  • Double Suspended Track System for a perfectly flat finish
  • Wind-resistant — stays locked in track under heavy gusts
  • Dual screen option: fabric & mesh in one frame
  • Child-safe mesh, magnet side-track locking
  • Multiple frame finishes · 5-year hardware warranty
ConfigurationHead BoxMax WMax H
ZPL85 — Single door85×85mm3500mm4000mm
ZPL85 — Single, concealed track85×85mm3500mm4000mm
ZPL110 — Single door110×110mm4500mm4500mm
ZPL110 — Single, concealed track110×110mm4500mm4500mm
ZPL85 — Double door85×85mm7000mm4000mm
ZPL110 — Double door110×110mm12000mm4500mm
Note: max height and width are ultimately set by the height-to-width ratio of the opening — confirm against the exact frame before ordering.
System 02 — Blume Screens

Touch a button, or let the schedule do it

Roller screens driven by a Somfy motor, controlled from a handheld remote or folded into a smart-home routine. Fabric is TuffScreen: tightly woven for daytime shade and night-time privacy, rated pet-friendly and scratch-resistant.

  • Remote-controlled Somfy motor with smart-home automation
  • Custom-built to wide doors, patios and pergolas
  • Roll-up box types: Box 90 / Box 110 / Box 150
  • Built-in thermal protection against motor overheating
  • Indoor and outdoor blind configurations
Operating notes: avoid rain and winds above 25 mph. Running the motor 2–3 times back to back can trigger the thermal cutout; it resumes after a 5–10 minute cool-down.
SystemHead BoxMax WMax H
MWZ 110 Motorized System110×110mm6000mm4000mm
MWZ 150 Motorized System150×175mm10000mm5000mm
Single Blume roller screenBox 90/110/150up to 6000mmup to 3500mm
TuffScreen® Fabric
Openness45%
Weight / thickness7.1 oz/sq yd · 0.027″
Bond strength42 lb
Colorfastness (12hr)AATCC grey-scale grade 4 min
System 03 — 22mm Retractable

Fifteen millimetres of pleat, twenty-two of frame

A roller-bearing pleat system built for large openings: the 15mm pleat keeps the stacked screen slim, and the whole track needs only 22mm of depth. Insect mesh and sun-shading fabric can share one frame.

  • Special polyester mesh — anti-dust and waterproof
  • Aluminium frame, grade 6063, 1.6mm thickness
  • Bottom guide options: 10 / 15 / 25 / 40mm
  • Magnet locking, operable from inside or outside
  • Rollers on ball bearings · wind-resistant cords
ProfileWithout jointWith joint
PVL 22 — Single2500×3000mm—
PVL 22 — Double2500–5000×3000mm—
PVL 22 — Vertical1500×1500mm—
PVL 29 — Single / Central4600×3300mm2500×4000mm
PVL 29 — Double9000×3300mm5000×4000mm
PVL 39 — Single / Central / Double4600×3300mm2500×4000mm
Care: vacuum tracks weekly, clean mesh with warm water and mild soap only — never a pressure washer or bore/tank water — and apply a silicone track lubricant every three months.
Why Choose Us

What a closed screen buys you

Sleep Better

Wake up refreshed, free from buzzing, biting and restless nights.

No Unwanted Guests

Mosquitoes, insects and dust stay outside where they belong.

Sun Protection

Filter harsh light without losing the view — balance glare and comfort.

Pet & Child Safe

Scratch-resistant, magnet-locked mesh built for households, not showrooms.

Reference Sites

Fitted across the UAE

Al Ghurair Villa, Al Khawaneej — Dubai Private Villa, Palm Jumeirah — Dubai 22 Carat Villa, Palm Jumeirah — Dubai Royal Luxury Villa — Abu Dhabi Atrad Villa, Shaqbout — Abu Dhabi 150 Club Villas, Dubai Hills 88 Villas Golf Groove, Dubai Hills Citadel Resort Villas, Al Barsha — Dubai Lake View Apartments, Green Community DIP
